Kubota BX Step Kit
SKU# BXSTEP
Click here to watch a video of the BX Step Kit being installed start to finish.
No Drilling Required!
This step will ONLY work with the factory Kubota front end loader mounts that have the factory 1.25” hole on the side. You can take your loader on or off, but the loader mounts must stay in place to use the step. The step attaches to both the main frame of the tractor and to the side of the loader mount for maximum support to withstand impact from all directions.
This step CAN be used with OR without the 54”, 60” mower deck and utilize full range of height and also the deck can be removed or installed with no interference. (It will NOT work with the Kubota drive over deck brackets that are sometimes found on the newer models.)
Will NOT work with Kubota BX23S, BX24, BX25 as the backhoe subframe will interfere with the frame mount for the step
CNC laser cut and formed
USA 3/16” steel throughout
Actual step is 7 1/2” deep by 8 1/2” wide with raised holes for traction
Reduces the step height by 6”
Comes with all mounting hardware and instructions to install.
Powder coated Orange to a perfect color match.
Fits tractor models:
BX 1850, BX 1860, BX 1870 BX1880
BX 2350, BX 2360, BX 2370, BX2380
BX 2660, BX2670, BX2680
