Universal Workmaster with D rings
SKU: UWMDR.
$169.00
Features:
(2) 5/16” forged grab hooks (G70) rated at 4700lbs WLL (Accepts 3/8” chain and under)
(2) 1/2” forded D rings (4,000 lb WLL (Working Load Limit)
(1) 2” receiver with 5/8” center hole
Mig welded construction
Full Industrial Grade E-Coat and Powdercoated Satin Black Finish
All grade 8 hardware included (Your choice of bolt length)
Instructions for mounting
1/2” Drill bit required. (Sold separately)
The Universal Workmaster was designed to work on many different tractor buckets of different sizes and shapes. Please measure the top portion of your bucket to verify if you have enough room to mount. The universal workmaster. It is ok if the backside of the workmaster plate hangs off a portion of the bucket, as long as you have the room to mount the bolts in your bucket. Also inspect the underneath portion of the top of your bucket to determine the length of the bolts that you will need. Most tractor buckets are single walled steel and will use 1.25” bolts for the installation. If the top of your bucket is double walled construction, you will need longer bolts for the installation. You will need to determine what length bolts you will need. We offer 3 different lengths of bolts when ordering. Please select which bolts you will need below
Compatible with:
Kioti: CS 2210, CS2410, CS 2510. (Select 1.25” bolts)
Kioti: CK 2610, CK2620, CK3510, CK3520, CK4010, CK4020 (Select 3” bolts). Works on the 66” gray bucket. If you have the 66” black bucket, this plate will NOT work.
TYM/Branson: 2515 H/R, 3015 H/R, 3515 H/R, 3620 H/R, T494, T574HC (Select 1.25” bolts)
Bad Boy: 4025H, 4025HL 4035H 4035HL 4035CHL (Select 1.25” bolts)
John Deere 650,655,670 with model 60 and model 51 loaders
John Deere 750,755,770 with model 70 and model 70A loaders
John Deere 850, 855 with model 70 and model 70A loaders
John Deere 950, 955 with model 70 and model 70A loaders
John Deere 1050 with model 75 loaders
John Deere 425,445,455 with model 40 Loaders,
John Deere X400 series, X500 series, and X700 series with model 45 loaders
If you tractor is not listed above, You will need to make sure the universal workmaster plate will fit correctly on your tractors bucket. The plate is designed to be mounted on the top, center portion of the tractors bucket. Please take all necessary measurements to ensure proper fit. The top portion of your bucket must have a depth of 2 3/4” or more for proper mounting. Also make sure the underneath side of your bucket has room and access to drill the holes and attach all hardware. Please refer to the product picture of dimensions of the product.
